At the "Microelectronics 2024" forum, INEUM named after I.S. Brook (part of the Avtomatika concern of the Ruselectronics holding of the Rostec State Corporation) presented a Russian single-board computer based on "Elbrus" processors. It is designed for use in various industries and at critical infrastructure facilities.
The MP21 module (TEGR.467144.004) based on the "Elbrus-2C3" processor is made in the Com Express Type 6 Compact form factor (95×95 mm). It is an embedded single-board computer for industrial use in a frameless design for use as a mezzanine, installed on specialized carrier boards.
MP21 is a processor core with integrated peripheral interface controllers and a video controller, soldered RAM, and an integrated solid-state drive with a capacity of 60 to 480 GB (the drive is optional).
The module can be supplied with a heat-spreading plate that transfers the generated heat to the cooling structures of the customer's product.
The "Elbrus-2C3" processor's integrated graphics core allows the module to be widely used in information display systems.
Main technical characteristics of MP-21:
- processor 1891VM068 ("Elbrus-2C3"), 2 cores, clock frequency not less than 1600 MHz;
- RAM ― one channel DDR4 SDRAM with ECC, 8 GB (optionally 4 GB), soldered;
- video ― two HDMI (resolution up to 4096x2160 60Hz), two-channel LVDS (resolution up to 4096x2160 30Hz);
- hardware acceleration DirectX 10, OpenGL 3.2, OpenGL ES 3, Vulkan 1.0, OpenCL 1.2, OpenVX 1.x;
- hardware acceleration of VP9, H.264, H.265, VC1, MJPEG encoding/decoding;
- 2 channels Ethernet 10/100/1000 Mbit/s (second channel via additional connector XP1);
- 8 USB 2.0 ports with HS, FS and LS speed support; 4 USB 3.0 ports;
- 2 SATA 3.0 ports;
- 2 UART ports (LVTTL level);
- SPI interface;
- I2C interface;
- SMBus interface;
- PCI Express 3.0 interface*;
- audio input/output ― HDAudio;
- 8 general purpose input/output lines (IO);
- real-time clock with the possibility of powering from an external lithium battery;
- watchdog timer ― internal, with the possibility of software control;
- power supply from a 12V DC source or +12V/+5V_SB;
- module interface ― COM Express Module Type 6;
- power consumption no more than 40 W;
- operating temperature from minus 40 to plus 55 °С;
- overall size 95x95 mm; form factor COM Express Type 6 Compact;
- weight no more than 100 g (without heat-spreading plate).
